Excellence at all levels

Passenger Models (includes wheelchair accessible)

Model Drive Machine Room Required Rated Capacity (kg) No Persons Max Stops
MPH Hydraulic YES 630-1500 8-20 4

Description

Sed purus. Mauris tortor diam, laoreet quis, porttitor pulvinar, consequat id, tortor. Sed a lectus vel erat sagittis sollicitudin. Cras tempus suscipit tortor. Sed feugiat metus. Sed sed magna ut felis eleifend mollis. Aliquam erat volutpat. Sed vel odio. Cras imperdiet consequat sapien. Nam vulputate rhoncus ante. Donec pede.

Technical documents (.pfd):

View installation examples

Product characteristics

Application

Ideally suited for low to medium rise buildings with moderate passenger flow.

Capacity

600kg (8 persons) to 5000 kg (66 persons)

Speed

0.4 m/s to 1m/s

Power Supply

400V 3-Phase 50hz

Drive Unit

The Drive or Power Unit consists of the hydraulic tank, pump motor group, valve block and muffler. Generally the pumpmotor group is inside the tank and oil immersed. The valve block contains all the equipment which controls the fluid flow to allow the lift to carry out the acceleration, deceleration and smooth speed changes. Electronic soft start and soft stopping also available.

Control

Simplex, Duplex, Triplex groups available with down or full collective microprocessor control.

Machine Room Location

Machine can be located above, below, below at side, below at rear or remote from lift shaft if necessary.
Levelling Accuracy +/- 10mm

Product Characteristics
